Micro‑Hook Rim Design
The micro-hook structure reinforces the bead support, ensures the stable assembly of the tubeless tire, and effectively improves the handling stability and safety of high-speed riding.
MASTER Series | The Pinnacle of Integration
Where seamless one-piece carbon-spoke technology meets assembly-hole-free design:
the ultimate synthesis of stiffness, aerodynamics, and lightweight performance.
Crafted for those who define the limits.
Get product advice and professional support from your local cycling specialist.
MASTER Series | The Pinnacle of Integration
Where seamless one-piece carbon-spoke technology meets assembly-hole-free design:
the ultimate synthesis of stiffness, aerodynamics, and lightweight performance.
Crafted for those who define the limits.
Explore the technical features of this product.
The micro-hook structure reinforces the bead support, ensures the stable assembly of the tubeless tire, and effectively improves the handling stability and safety of high-speed riding.
Paint-free integrated carbon finish presents pure texture with low energy consumption and eco-friendly production.
One-piece aero carbon hub and spoke structure with anti-loose design boosts tensile strength and power transmission efficiency.
High-strength carbon spokes reduce rotating mass while improving acceleration and power transfer.
Select a category to view the specifications.
| Wheel Size | 622mm(700c) |
|---|---|
| Material | Carbon Fiber |
| Tire Compatibility | Tubeless Ready, Tubeless Tape Free |
| Bead Type | Hooked |
| Rim Depth | 50mm |
| Inner Width | 23mm |
| Outer Width | 30mm |
| Front Hub Spacing | 12x100mm |
|---|---|
| Rear Hub Spacing | 12x142mm |
| Bearing | S&S Ceramic |
| Brake Compatibility | Disc (Center Lock) |
| Freehub Type | Ratchet |
| Freehub Compatibility | Shimano HG/ SRAM XDR |
| Rim Finish | Raw Finish |
|---|---|
| Included Accessories | Pre-Installed Tubeless Valves |
| Weight (Pair) | 1308g±3%(Without tubeless valves) |
| Max load, Bike + User (Kg) | 270lbs/120kg |
| Compatible Tire Sizes | 700 x 28-45C |
| Recommended Tire Sizes | 700 x 28-30C |
| Certification | UCI Approved |
| Spoke Count | 18F/24R |
|---|---|
| Spoke Type | VONOA C001 ONE PIECE INTEGRATED CARBON |
